产品详细介绍
Gantry Eagle 800 欧吉索针对复杂的解决方案，是大工作区间、小占地面积和无法想象的加工能力的完美结合--在市场上取得成功的保证；在加工中大型工件时拥有决定性的竞争优势。
各轴行程：X/Y/Z 550/850/450 mm
油箱：长/宽/高 800/1100/480 mm
极好的工件尺寸和行程比、极高的动态性、精度再次提高
机床/Machine tool | |
| 机床重量/Weight of machine tool | 6200kg |
| 电源重量/Power supply weight | 640kg |
| 电源功率/Power supply | 16KVA |
| 继电/Relay | 32A |
| 电压/频率/Voltage / frequency | 400/50 |
工作槽/Working groove | |
| 类型/Type | 整体升降/Integral lifting |
| 工作槽内部尺寸（长x宽x高）/Internal size of working groove (long x width x height) | 800x1100x480mm |
| 最大液面高度可编程/自动/Maximum height of the liquid level can be programmed / automatic | 450mm |
工作头部/Working head | |
| 最大工件托盘重量/Maximum weight of workpiece | 200kg |
| 工作台到安装版距离最小/最大/Working table to install version distance min / Max | 135/585mm |
C轴/C axis | |
| 转速（可调节）/Speed (adjustable) | 1-20min |
| 最小指令值/Minimum instruction | 0,001° |
| 最大手动电极交换重量/Maximum manual electrode exchange weight | 50kg |
| 最大自动电极交换重量/Maximum automatic electrode exchange weight | 15kg |
| 最大运动惯量/Maximum motion inertia | 0,4kg/㎡ |
| 扭矩/Torque | 120Nm |
工作台/workbench | |
| 工作台尺寸（长x宽）able size (length x width) | 760x1000mm |
| 最大工件重量/Maximum weight of workpiece | 2000kg |
行程/Trip | |
| X/Y/Z在加工槽内的行程/X/Y/Z stroke in the processing slot | 550x850x450mm |
| Y（电极交换和装卸时行程）/Y (electrode exchange and loading and u | 1180mm |
控制系统/Control system | |
| PC-NC对话/PC-NC dialogue | 2x32bit |
| 驱动类型/Drive type | 数字交流伺服电机/Digital AC servo motor |
| XYZ轴移动速度/XYZ axis movement speed | Max5000mm/min |
| 最大高速抬刀速度/Maximum high speed lift | 18000mm/min |
工作液箱/Working liquid box | |
| 滤芯类型/Type of filter element | 筒（内置）/Cylinder (built in) |
| 过滤面积/Filtration area | 32㎡ |
| 工作液箱总容量/Total tank capacity | 800ltr |
电极交换系统/Electrode exchange system | |
| 类型/Type | 旋转盘/Rotating disk |
| 电极库（可选）/Electrode Bank (optional) | 20（30） |
| 联合电极库作为选配/Combined electrode bank as an option | |
| 允许电极重量/Allowable electrode weight | |
| -单一电极/Single electrode | 15kg |
| -总体重量/Total weight | 60kg |
电源/Power Supply | |
| 类型/Type | 脉冲形状自适应控制/Adaptive pulse shape control |
| 最大工作电流(选配)/Maximum operating current（optional) | 60（110）A |
额外特点/Additional features | |
| 自动中央润滑/Automatic central lubrication | 标准配置/Standard configuration |
| 冷却系统、功率/Cooling system, power | 3.9KW |
| CO2灭火装置（D1D14497）灭火剂容量/Capacity of CO2 fire extinguishing equipment (D1D14497) | 8kg |
